FB012-250 - Dielectric Foam Microwave Absorber

Wavexorb Dielectric Foam Absorbers are lightweight, conductive carbon loaded materials which provide high levels of loss at all angles of incidence. Dielectric Foam Absorbers are effective in free space applications such as radomes or antennae. Wavexorb Dielectric Foam Absorbers are an economical solution, and provide broadband performance in a frequency range of 1GHz to 40 GHz.

NOTE: (...) = REQUIRED
[...] = OPTIONAL

(-01) 24" x 24" (609mm x 609mm)

(-02) 12" x 24" (305mm x 609mm)

(-03) 12" x 12" (305mm x 305mm)

[-A] Add -A for PSA backing

Examples:
FB012-250-03
FB012-250-02-A
Material: Lossy Foam
Color: Black

Thickness: 0.250" (6.35 mm)

Adhesive: 0.005" (0.13 mm)

Temp Range: -60°F to 250°F
(-51°C to 121°C)

RoHS Compliant
Contains no halogens
